Overview
The cartridge employs a fixed samarium cobolt magnet and high output coil combination so that a very light iron/nickel cantilever end-piece can be used instead of the much heavier permanent magnet used in conventional designs. This reduces the moving mass of the cartridge allowing the stylus to trace the record groove more faithfully. Because of their high output, Goldring 2000 series cartridges should be used with the standard moving magnet phono input of an integrated amplifier.
Use of a nude elliptical diamond offers high clarity and excellent tracking ability. This record cartridge will upgrade many mid-range turntables, allowing them to produce an even finer sound.
- Contact : Dicky Ng 012-3308893
- Contact : John Yew 016-2861000
- Email : [email protected]
| Weight | 0.4 kg |
|---|
Specification
| Frequency Response | 20 Hz – 20kHz +/- 3 dB |
| Channel Balance | within 2 dB @ 1 kHz |
| Channel Separation | better than 20 dB @ 1 kHz |
| Sensitivity | 6.5 mV 1.5 dB, 1 kHz @ 5 cm/sec |
| Static Compliance | 35 mm/N |
| Dynamic Compliance @ 10 Hz | 16 mm/N |
| Vertical Tracking Angle | 24 |
| Stylus Radius | Nude Elliptical |
| Stylus Type | Replaceable |
| Load Resistance | 47 k |
| Load Capacitance | 100 – 200 pF |
| Internal Inductance | 680 mH |
| Internal Resistance | 550 |
| Cartridge Mass | 7.4 g |
| Cartridge Mass ( inc. fixing screws) | 8.6 g |
| Fixing Centre | 0.5″ (12.7 mm) |
| Playing Weight | 1.5 – 2.0 g (1.7 g nom.) |
Product Reviews
“There’s a really great balance to the lowest octaves, which gives drive to rock, poise to classical and, of course, a very natural tone to male vocals. Precisely because the bass is so well balanced, though, it doesn’t leap out and assault you the way some budget cartridges seem to.” #TechRadar
Be the first to review “Goldring
2300
Moving Magnet
Cartridge
(Made in Japan)”
You must be logged in to post a review.
