Ortofon
Pick it 25A
Stylus
(Made in Denmark)
(Pre-order)

Overview

Output voltage – 5.5 mV
Frequency response – 20 – 24.000 Hz
Channel separation – >25dB @ 1kHz
Compliance, dynamic, lateral – 25 µm/mN
Stylus type – Elliptical
Stylus tip radius – r/R 8/18 µm
Tracking force range – 1.25-1.75 g
Tracking force, recommended – 1.5 g
Tracking angle – 20°
Internal inductance – 580 mH
Recommended load resistance – 47 kΩ
Recommended load capacitance – 200-600 pF
Stylus colour – Blue
Stylus weight – 5 g
