Fidek
Professional Cinema
System 2
(Display Set)

Overview

FDM-8250MA LCR Channel Speaker – 3 Pieces

• 3-Way Luxurious Cinema Main Speaker
• Three-way, two- or three-way drive selectable
• Double ten inch medium frequency system, high power, low distortion
• Uses phase plug coupling technology to improve dialogue clearness.
• Ultra-thin, very suitable for cinemas with limited distance to the back wall
• Middle and high frequencies can be adjusted up and down, left and right

FD-500MVP Surround Channel Speaker – 2 Pieces

• The FD400 MVP/FD500MMP is a new high-power, high-sensitivity speaker system developed for Dolby Atmos and IMAX Theater. It offers wall-mounting or ceiling-mounting installations.
• Both tweeter and woofer use the NdFeB power system, and NdFeB is widely used for special high-quality products due to its excellent magnetic properties (small size, high magnetic performance, and relatively light weight). Woofer uses 12-inch (55mm) aluminum wire voice coil, tweeter uses 1.75 inch 444mm) aluminum wire voice coil.
• System sensitivity up to 101dB, power reached 500 watts. Its performance can meet the special requirements of the IMAX Theater.
• Frequency division network uses imported high-quality components to ensure pure sound quality, accurate frequency, built-in tweeter protection, can reduce distortion and improve product safety.
• Combined with the rotating bracket, it ensures the precise adjustment of the angle required by the cinema.

FD-500MVP Surround Backchannel Speaker – 2 Pieces

• The FD400 MVP/FD500MMP is a new high-power, high-sensitivity speaker system developed for Dolby Atmos and IMAX Theater. It offers wall-mounting or ceiling-mounting installations.
• Both tweeter and woofer use the NdFeB power system, and NdFeB is widely used for special high-quality products due to its excellent magnetic properties (small size, high magnetic performance, and relatively light weight). Woofer uses 12-inch (55mm) aluminum wire voice coil, tweeter uses 1.75 inch 444mm) aluminum wire voice coil.
• System sensitivity up to 101dB, power reached 500 watts. Its performance can meet the special requirements of the IMAX Theater.
• Frequency division network uses imported high-quality components to ensure pure sound quality, accurate frequency, built-in tweeter protection, can reduce distortion and improve product safety.
• Combined with the rotating bracket, it ensures the precise adjustment of the angle required by the cinema.

FD-800SB 18″ Subwoofer – 2 Pieces

• FDM800SB is a single 18″ cinema subwoofer system that fully reflects the perfect combination of high performance unit and reasonable cabinet structure, providing a high level of sound pressure and deep power bass effect.

FCQA-8631 Dolby Reference 8-Ch. Processor

• New appearance and software design, simpler operation, more convenient use and more stable work.
• Support a variety of audio signal input, so that users can make corresponding choices for different audio signals.
• Supports decoding of 8 digital audio signal inputs and 8 analog signal inputs of 1.3K and 2K digital cinema server.
• Support one-way optical fiber coaxial digital audio input.
• Supports frequency division, equalization, gain adjustment of the main speaker, and powerful digital signal processing capability.
• Built-in Fidek sound system FD, FDM series speaker technical parameters, easy to debug the entire process; built-in standard test program standard test signal, standard test microphone, can accurately debug the theater audio equipment.
• Through the network equipment of the theater, FCQA-8631 can centrally debug, monitor and control the sound-receiving equipment of multiple cinemas in the computer room.
• Support data backup card, one machine and one card, the card is automatically updated, no need for professional re-commissioning when the equipment is interchanged.
• All digital and analog input signals are ground-separated input technology to ensure minimum system noise and lower requirements for the cinema ground environment.

FCM-1000 2-Ch. 1000w Power Amplifier – 3 Pieces

• The new class H switch design, ensure the safety of the operation and reliability;
• 1/4 input interface, balance the XLR jack, a variety of connection mode, can choose a stereo, or bridge connecting mode;
• The power transformer and the large capacity filter capacitor, ensure stable dc power supply voltage, the thrust of the power amplifier;
• Prevent distortion at high pressure circuit, ensure the safety of the power amplifier and speaker system work;
• Good heat dissipation system, the machine has been working in the best condition;
• Strong and durable casing and the internal structure of reasonable quality, to ensure the long-term operation of the power amplifier.

FCM-800 2-Ch. 800w Power Amplifier – 2 Pieces

• The new class H switch design, ensure the safety of the operation and reliability;
• 1/4 input interface, balance the XLR jack, a variety of connection mode, can choose a stereo, or bridge connecting mode;
• The power transformer and the large capacity filter capacitor, ensure stable dc power supply voltage, the thrust of the power amplifier;
• Prevent distortion at high pressure circuit, ensure the safety of the power amplifier and speaker system work;
• Good heat dissipation system, the machine has been working in the best condition;
• Strong and durable casing and the internal structure of reasonable quality, to ensure the long-term operation of the power amplifier.

FCM-1200 2-CH. 1200w Power Amplifier

FBR-10MVP Surround Spk. Wall Bracket – 4 Pieces

FRK-1800 40U Equipment Storage Rack

• Used to store audio processors, amplifiers, and theater peripherals, the equipment can be placed in the machine room in an orderly manner.
• A fan is placed on the top of the cabinet to enhance heat dissipation.

RC-ST lcr Speaker Stand – 3 Pieces
