BIK
BJ-A88
Karaoke Amplifier

Specification

> Max Output Power: 350W +350W/4 ohms, 240W + 240W/8ohms
> Total Harmonic Distortion: 0.09%
> Speaker Impedance: 4-8ohms (A or B), 8-1 ohms (A + B)
> Audio Input: VOD, AUX, Optical, Coaxial: 200mV
> MIC Input, MIC-1, MIC-2/A, MIC-3/B: 200mV
> MIC Output: High Level 3V, Low Level 100mV, Pre Amplifier Output 5V, Sub woofer Output 5V
> Frequency Response Microphone: 20Hz~20kHz +-3dB
> Frequency Response Music: 20Hz~20kHz+-3dB
> Tone Control Music Bass: ±8dB (100Hz)
> Tone Control Music Midrange: ±7dB (1Khz)
> Tone Control Muisc Treble: ±8dB (10kHz)
> Microphone Bass: ±8dB(100kHz)
> Microphone Midrange: ±7dB(1kHz)
> Microphone Treble: ±8dB (10kHz)
> Echo Bass: ±3dB(100Hz)
> Echo Midrange: ±3dB(1kHz)
> Echo Treble: ±3dB (10kHz)
> Video Input: 1Vp-p/75 ohms
> Video Output: 1Vp-p/75 ohms
> Power Voltage: AC220V-240V/50Hz
> Power Consumptions: 500W
> Dimensions in mm (WxHxD): 430 x 148 x 327
> Weight: 17kg
> Accessories: Owner’s Manual, Power Cable, Remote Controller
