Overview
The N25AMP is the most advanced all-in-one network audio player in the world, featuring 150 watts powerful amplifier built-in, a Sabre32 Reference DAC chip and high-performance Dual Core ARM Cortex A9 processor, running at 1.0Ghz. It has been designed to meet all the requirements of digital music playback, keeping pace with today’s digital world. The N25AMP is based on long proven cocktailAudio technologies, such as the hardware circuit design and versatile custom-designed software, developed by in-house R&D team, to achieve the best audio performance and ease of use across all its functions.
Simply connect the bookshelf speakers and you will have a great HiFi system with wonderful sound. It offers high-quality playback from local USB storage, home network sources like NAS, major online streaming services, internet radio, DAB+/FM radio, aptX HD Bluetooth, Soptify Connect, Airplay for iOS devices and much more. Optionally, the N25AMP provides Bluetooth transmission, allowing playback of music from the N25AMP via Bluetooth headphones or speakers. It also supports playback covering a huge variety of audio format including DSD, MQA, DXD, HD FLAC, HD WAV, CAF, ALAC, AIFF and more.
Additionally, for use as a complete and convenient music system throughout the home, the N25AMP provides not only Multiroom function(Group Play), carefully developed by cocktailAudio team over several years, but also a HDMI eARC Input to connect with TVs.
Finally, when paired with optional extras, you can expand its functionality as a music server, aptX Bluetooth transmitter, and more.
- Contact: Dicky Ng 012-3308893
- Contact: John Yew 016-2861000
- Email: [email protected]
| Weight | 3 kg |
|---|---|
| Selection | Black, Silver |
| Option | Basic, Purchase with Purchase |
Specification
| Model name | cocktail Audio N25AMP | ||
|---|---|---|---|
| Host CPU & Memory | CPU: Dual Core ARM Cortex A9 running at 1.0GHz | ||
| Main Memory: DDR-1066 1GByte | |||
| NAND Flash 8GByte | |||
| Display | 4.6″ TFT LCD(800 x 320pixels)(* able to connect to ext. screen via HDMI out) | ||
| Interface | Key & Jog(Volume/Scroll), IR Remote Control, Customized Remote App for iOS and Android devices | ||
| Amplifier (Speaker Out) | Rated output 75W + 75W@1Khz, 8ohm, 0.1% THD (Total 150W) (Max Total 230Watts) | ||
| Analog Out (Sabre32 ES9018K2M DAC) | Unbalanced (PRE-OUT) |
RCA, Dynamic Range: 127dB (Max 2Vrms, Stereo) THD +N: -110dB(0.0003%) Frequency Response : 20~80KHz(±0.2dB) |
|
| Digital Output (Variable/Fixed) |
COAXIAL x 1 | S/PDIF 75ohm RCA, Sample rate: up to 24bit/192KHz | |
| TOSLINK x 1 | S/PDIF, Sample rate: up to 24bit/192KHz | ||
| USB Audio x 1 | USB Audio Class2.0 Output | ||
| HDMI Out x 1 | HDMI Audio Out(*Shared with HDMI Out for external screen) | ||
| Digital Input | COAXIAL x 1 | Sample Rate: up to 24bit/192Khz | |
| TOSLINK x 1 | Sample Rate: up to 24bit/192Khz | ||
| HDMI eARC IN | Up to PCM 192KHz/24Bit | ||
| USB Audio Input (USB DAC) |
USB B type connector, USB Audio Class 2.0 input (support up to PCM 384Khz/32Bit, DSD Native 256, and DoP 128) |
||
| Bluetooth SINK(Receiver) | BT 5.0 supports | Profile : A2DP/AVRCP Audio Codec: SBC, AAC, aptX, aptX LL, aptX HD |
|
| TUNER | DAB+ / FM Radio | Selectable for DAB/DAB+ or FM Radio | |
| Connectivity | USB Host | USB3.0(5V/1A) x 2 at rear USB2.0(5V/1A) x 1 at front |
|
| Network | Wired | Giga Fast Ethernet(10/100/1000Mbps) | |
| Wireless(Option) | ** 802.11b/g/n WiFi USB dongle(Option) | ||
| Codec & Format supported | MQA, PCM 384Khz/32Bit, DSD(DSD64, DSD128, DSD256), DXD(24Bit/352.8KHz), HD WAV(24Bit/192KHz), HD FLAC(24Bit/192KHz), APE/CUE, WAV, FLAC, ALAC, AIFF, AIF, AAC, M4A, MP3, WMA, CAF, Ogg Vorbis, PCM, M3U, PLS, etc |
||
| Network Protocols Supported | UPnP(DLNA) Server/Client/Media Renderer, Samba Server/Client, FTP Server, Web Server, etc | ||
| Internet Services | Internet Radio | Airable | |
| Online Music Services | Amazon Music, TIDAL, TIDAL MQA, Deezer, Qobuz, Napster, HighResAudio, Spotify Connect | ||
| Supported OSD languages | English, German, French, Spanish, Italian, Polish, Dutch, Russian, Traditional Chinese, Simplified, Chinese, Japanese, Korean,(To be added by request) | ||
| Isolated Power management | Linear Transformer | For audio signal management | |
| 400W internal SMPS | For digital CPU management | ||
| Power Source | 220V area | AC 220V – 240V, 50/60Hz | |
| 110V area | AC 110V – AC 120V, 50/60Hz | ||
| Mechanical | Material | Front | 10mm thickness aluminum by CNC cutting |
| Knob | Aluminum by CNC cutting | ||
| Body | Metal | ||
| Dimension | Without foot | 440mm(W) x 260mm(D) x 61mm(H) | |
| With foot | 440mm(W) x 260mm(D) x 73mm(H) | ||
| Certificate | CE, FCC, EMI, etc | ||
| Optional Items | |||
| WiFi USB Dongle | * Only the WiFi USB Dongle(802.11b/g/n) that the N25AMP manufacturer provides will work properly with the N25AMP | ||
| USB External Storage | * Various brands of external USB storages available in the markets will work with the N25AMP | ||
| Bluetooth Transmitter | * Only ‘Bluetooth Transmitter Module’ that the N25AMP manufacturer provides will work properly with the N25AMP * BT5.0 supports * Profile: A2DP/AVRCP * Audio Codec: SBC, AAC, aptX, aptX LL, aptX HD |
||
